TroublePix wireless triggering
With TroublePix you can now start/stop a recording or trigger a Pre/Post event remotely using one of the following supported radio triggers:
- Interlink VP4910 RemotePoint Jade. This device allows you to program up to 4 buttons which can emulate keyboard input, having an operating range of 150' (46m).
- Elinchrom EL-Skyport. The EL-Skyport system has a studio operating range of 164' (50m), and 394' (120m) outdoors. http://www.smklink.com/index.php?id=NzA2
TroublePix includes various keyboard shortcuts like:
| Keyboard shortcut | Description |
|---|---|
| F1 | Open TroublePix User Guide |
| F2 | Save |
| F3 | Start/Stop Playback |
| F4 | Toggle Review mode |
| F5 | Start/Stop Recording |
| F6 | Switch to Camera Panel |
| F7 | Switch to History Panel |
| F8 | Switch to Status Panel |
| Alt+M | Show Marker List |
| Alt+S | Show Status log |
| F9 | Open TroublePix Settings |
| Ctrl+F9 | Open TroublePix configuration file |
| F10 | Toggle "Fit Image To Window" mode |
| F11 | Mark Current Frame |
| F12 | Toggle Full Screen |
| Space | Emulate Pre/Post Trigger |
| Ctrl+O | Open Sequence |
| Ctrl+Shift+O | Open AVI |
| Ctrl+X | Close current file |
| Ctrl+Shift+X | Close all opened files |
| Ctrl+S | Save As... |
| Ctrl+I | Export current frame to image |
| Ctrl+W | Export to Windows Movie (*.avi) |
| Ctrl+Q | Export to QuickTime Movie (*.mov) |
| Ctrl+Shift+P | Print current frame |
| Ctrl+Shift+V | Print preview |
| Ctrl+Shift+S | Open Printer Settings dialog |
| Alt+F4 | Quit the application |
| Ctrl+T | Show Thumbnails |
| + or Ctrl+"+" | Zoom In |
| - or Ctrl+"-" | Zoom Out |
| * or Ctrl+0 | Reset Zoom |
| Ctrl+B | Toggle Bayer conversion |
| Ctrl+1 | Switch to GBRG Bayer pattern |
| Ctrl+2 | Switch to GRBG Bayer pattern |
| Ctrl+3 | Switch to BGGR Bayer pattern |
| Ctrl+4 | Switch to RGGB Bayer pattern |
| Ctrl+P | Change Bayer pattern |
| Ctrl+C | Toggle Auto Color Balance |
| Ctrl+V | Show/Hide timestamp overlay |
| Ctrl+G | Load grabber |
| Ctrl+Shift+G | Reload current grabber |
| Ctrl+Alt+G | Load preferred grabber |
| Ctrl+L | Toggle LIVE mode (grabber acquisition) |
| Ctrl+H | Adjust grabber features |
| Ctrl+J | Adjust LIVE adjustable features |
| Ctrl+D | Adjust advanced grabber settings |
| Ctrl+F | Change buffer count |
| Ctrl+Y | Launch Batch Processor |
| Ctrl+E | Launch Sequence Header Editor |
| Ctrl+R | Launch Register Manager |
| Ctrl+N | Launch NorPix Logger |
| Ctrl+K | Launch benchmark tool |
| Ctrl+U | Check for updates |
| Ctrl+Shift+F | Send feedback to NorPix |
| Ctrl+Shift+L | Display license information |
| Ctrl+A | Display program information and version number |
| Alt+1 | Activate Camera Viewer |
| Alt+2 | Activate Playback Viewer 1 |
| Alt+3 | Activate Playback Viewer 2 |
| Alt+4 | Activate Playback Viewer 3 |
| Alt+5 | Activate Playback Viewer 4 |
| Alt+6 | Activate Playback Viewer 5 |
| Alt+7 | Activate Playback Viewer 6 |
